The compact models give systems designers increased flexibility by offering vastly improved music playback, additional coverage patterns and higher output in attractive paintable enclosures. Both models include front-loaded LF drivers in highly reinforced enclosures for natural, nonresonant low frequency reproduction, while identical voicing ensures a uniform listening experience.
Features:
- Ultra-compact size, high output
- Premium music applications full frequency horn, professional, all weather
- With switch selection 70V, 100V, and 8 ohms
- With IP, SIP Net audio with our Eco IP system
- IP 55 for outdoor application
Ordering Code:
- RC-200: 8 ohm 200W
- RC-200T: 100V line 200W
- RC-200 IP : 200W IP Net audio, Powered
- RC-200 SIP : 200W SIP Net audio, Powered
- RC-300: 8 ohm 300W
- RC-300T: 100V line 300W
- RC-300 IP : 300W IP Net audio, Powered
- RC-300 SIP : 300W SIP Net audio, Powered
| MODEL | RC-200 | RC-200T | RC-300 | RC-300T |
| Rated power | 200W@8ohm | 25W/50W/100W/200W@100V | 200W@8ohm | 37.5W/75W/150W/300W |
| 200W@8ohm | 200W@8ohm |
| Maximum power | 400W | 400W | 400W | 400W |
| Input | 8ohm | 70V/100V/8ohm | 8ohm | 70V/100V/8ohm |
| Sensitivity (1W/1M) | 103dB ± 3dB | 103dB ± 3dB | 103dB ± 3dB | 103dB ± 3dB |
| Frequency response | 70Hz-18KHz | 70Hz-18KHz | 70Hz-18KHz | 70Hz-18KHz |
| Radiation angle | ∠90-100° | ∠90-100° | ∠60-120° | ∠60-120° |
| Speaker unit | 10”*1(Bass), 1”*1(Treble) | 10”*1(Bass), 1”*1(Treble) | 12”*1(Bass), 1.5”*1(Treble) | 12”*1(Bass), 1.5”*1(Treble) |
| Product size | 385*355*348mm | 385*355*348mm | 375*435*395mm | 375*435*395mm |
| Weight | 13.5KG | 15KG | 18.5KG | 20KG |
