The compact models give systems designers increased flexibility by offering vastly improved music playback, additional coverage patterns and higher output in attractive paintable enclosures. Both models include front-loaded LF drivers in highly reinforced enclosures for natural, nonresonant low frequency reproduction, while identical voicing ensures a uniform listening experience.
- Ultra-compact size, high output
- Premium music applications
- Full frequency horn, professional, all weather
- With switch selection 70V, 100V, and 8 ohms
- IP 55 for outdoor application
Ordering Code:
RC-150: 8 ohm 150W
RC-150T: 100V line 150W
| Model | RC-150 | RC-150T |
| Rated power | 150W@8ohm | 18.5W/37.5W/75W/150W@100V
9.5W/18.5W/37.5W/75W@70V 150W @8ohm |
| Maximum power | 300W | 300W |
| Input | 8ohm | 70V/100V/8ohm |
| Sensitivity (1W/1M) | 93dB ± 3dB | 93dB ± 3dB |
| Frequency response | 80Hz-18KHz | 80Hz-18KHz |
| Radiation angle | ∠120° | ∠90-100° |
| Speaker unit | 10”*1(Bass), 3”*1(Treble) | 10”*1(Bass), 3”*1(Treble) |
| Product size | 345*355*297mm | 345*355*297mm |
| Weight | 10.5KG | 11KG |
