Highly flexible mixer amplifiers available at 120, 240, 350 and 500W RMS power and equipped with all necessary microphone and aux inputs for a wide variety of voice and background music applications such as retail shops, restaurants and bars, service centers, houses of worship, warehouses and many more.
Features
- 4 microphone and 2 auxiliary inputs
- Priority:EMC >MIC1>MIC2, MIC3, AUX1, AUX2
- Individual input gain controls with master volume control
- With Phantom power supply to mics
- Light weight design
- Mp3/TUNER/Bluetooth module with screen display
- 100V and 4-16 Ohms rear panel switchable speaker outputs
- Standard 1U 19 inch size with detachable mounting ears
- Automatic mute function for paging and announcements
- Speaker output short circuit protection
|
| MODEL | MA-120AD | MA-240AD | MA-350AD | MA-500AD |
| Rated Power Output | 120W | 240W | 350W | 500W |
| Output | 100V or 4 – 16 ohm switchable | | | |
| THD | 60 – 16,000 Hz, +/- 3dB | | | |
| Frequency Response | Less than 0.5% at 1kHz (1/3 Rated Power) | | | |
| Tone Controls | Better than 80dB | | | |
| S/N Ratio | BASS: 100 Hz (+/- 10dB), TREBLE: 10k Hz (+/- 10dB) | | | |
| Controls | All input gain, 1 treble, 1 bass, 1 mute, and power switch | | | |
| Cooling | Internal 12VDC fan, extensive heat sinking | | | |
| Indicators | Power indicator LED, PROT, 100V, 4-16 OHM, CLIP, SIG | | | |
| Power Consumption | Current limiter, short circuit and thermal protection circuits | | | |
| Protection | 170W | 340W | 500W | 720W |
| Power Requirments | 220-240V AC, 50/60 Hz | | | |
| Dimensions | 44.5(H) x 483(W) x 330(D) mm | | | |
| Built-in Dimensions | 1 U rack 19 inch | | | |
| Net Weight | 5.6kg | 5.6kg | 5.7kg | 5.7kg |
| Finish | Panel: Aluminium plate, black Case: steel plate, black | |
