Engineered for Performance
The speakers’ dispersion angle of 110 degrees effectively
reduces hot spotting for a more uniform distribution. This
provides greater flexibility in speaker spacing, because
fewer speakers are required to cover the same amount of
square footage.
Built for Sound
A two-way design delivers high sound quality, while Nomex
spiders and high-temp voice coils ensure longevity, and
a fluid-cooled neodymium tweeter delivers smooth, highfrequency performance.
Designed for Versatility
A paintable grille and baffle allows custom color
matching for any commercial application.
Woofer: 6½” Treated Paper Cone, Nomex Spider
& High Temp Voice Coil
Tweeter: 1/2” Fabric Dome, Neodymium Motor,
Ferrofluid Cooled
Power Handling: 50 Watts RMS, 125 Watt Peak
Dispersion Angle: 110 degrees
Transformer Tap Settings: 0.5W, 1W, 2W, 4W
Frequency Response
(-6dB): 58Hz - 20KHz
Sensitivity -2.83 V / 1 Meter: 87
Adjustments: N/A
Color: White
Crossover Frequency: 4.3 kHz
Connector Type: Flying Leads
Weight: 2.1 lbs. each
Grill Type: Aluminum Micro-Perf Mesh
Cutout Dimensions: 7.7” diameter
Mounting Depth: 3.4”
Finished Dimensions: 8.5” diameter, 3” D
